Product Overview
Aaon Adjustable Relay (R48600)
The AAON R48600 Adjustable Time Delay Relay is an OEM replacement control component used to delay circuit operation in AAON HVAC equipment. It supports an adjustable 6-to-480-second timing range and a 24–240 VAC/DC operating-voltage range, allowing a connected load to activate or deactivate after the selected delay.
Part Details:
- OEM adjustable time delay relay for AAON HVAC equipment
- Manufacturer part number R48600
- Adjustable 6-to-480-second timing range
- 24–240 VAC/DC operating-voltage range
- Delays relay-contact operation following an input signal
- Dimensions of approximately 2.25 inches wide by 2.1 inches high by 2.1 inches deep
FAQs:
Q: What does the AAON R48600 adjustable time delay relay do?
A: The AAON R48600 delays the opening or closing of relay contacts after it receives an input signal. In an HVAC control circuit, this permits a connected load or control function to activate or deactivate after a selected interval rather than immediately.
Q: What is the adjustable timing range of the AAON R48600 relay?
A: The R48600 has a stated adjustable timing range of 6 to 480 seconds. Confirm that this range matches the existing component and the control requirements documented for the AAON unit.
Q: What voltage does the AAON R48600 time delay relay support?
A: The R48600 is listed for 24–240 VAC/DC operation. Verify the circuit voltage and the markings on the existing relay before selecting it as a replacement.
Q: Is the AAON R48600 an OEM replacement relay?
A: Yes. R48600 is identified by established HVAC parts suppliers as an OEM AAON replacement relay. OEM status does not mean it is compatible with every AAON unit, so the exact part number and electrical configuration must still be checked.
Q: How can I determine whether the AAON R48600 fits my HVAC unit?
A: Confirm that R48600 appears on the existing relay, unit bill of materials, or applicable AAON parts documentation. Compare the equipment model and serial number, circuit voltage, required timing range, terminal arrangement, and physical configuration before ordering.
