Product Overview
Distech RE12DCSPDT Relay (no base)
The Distech Controls RE-12DC-SPDT is a 12 VDC, single-pole double-throw relay designed to convert a compatible Distech controller’s universal-output signal into a dry-contact relay output. It provides normally open and normally closed switching contacts for controlling higher-voltage or higher-current loads while isolating the controller circuit from the switched circuit. The RE-12DC-SPDT is the relay only; the RE-RT78724 relay base and RE-PTML0024 LED module are separate components.
Part details:
- 12 VDC coil with a 9.0 VDC operate voltage and 250 mW rated coil power
- One Form C changeover contact with normally open and normally closed contact paths
- 10 A at 250 VAC general-purpose contact rating
- 400 VAC maximum switching voltage and 2,500 VA breaking capacity
- Plug-in relay configuration with silver-nickel 90/10 contacts
- Relay only; RE-RT78724 base and RE-PTML0024 LED module are separate components
Documentation:
FAQs:
Q: What does the Distech Controls RE-12DC-SPDT relay do?
A: The RE-12DC-SPDT converts a universal-output signal from a compatible Distech controller into a dry-contact relay output. This allows the controller output to command a higher-voltage or higher-current circuit while maintaining electrical isolation between the controlling and switched circuits.
Q: Is the RE-12DC-SPDT compatible with every Distech Controls controller?
A: The manufacturer states that the relay is designed for use with Distech controllers and their universal outputs. Confirm that the controller output is compatible with the relay’s 12 VDC coil, 9.0 VDC operate voltage, and 250 mW rated coil power.
Q: Does the RE-12DC-SPDT include the relay base or LED module?
A: No. The RE-12DC-SPDT is the relay only. The manufacturer identifies RE-RT78724 as the corresponding relay base and RE-PTML0024 as the LED module, so verify which components are required before ordering.
Q: What are the contact and switching ratings of the RE-12DC-SPDT relay?
A: The RE-12DC-SPDT has one Form C changeover contact and is rated for a 10 A, 250 VAC general-purpose load. Its manufacturer specifications also list a 400 VAC maximum switching voltage and a 2,500 VA breaking capacity.
Q: How can I confirm that RE-12DC-SPDT is the correct replacement relay?
A: Confirm the complete part number on the existing relay and compare its coil voltage, contact arrangement, load rating, and required base with the manufacturer specifications. The RE-12DC-SPDT uses a 12 VDC coil and one Form C changeover contact; a relay with a similar number, different coil voltage, or different contact configuration should not be assumed interchangeable.
