Humphrey Solenoid Valve (310-21)

(No reviews yet) Write a Review
$66.60
SKU:
31021120V
MPN:
310-21
Condition:
New
Availability:
Usually ships within one business day.
Adding to cart… The item has been added

Product Overview

Humphrey Solenoid 310-21 Valve

The Humphrey 310-21 120V Solenoid Valve is a direct-acting, pressure-balanced poppet valve used to control air or inert gas in pneumatic equipment and control circuits. This 310 Series inline configuration has 1/8-inch pipe ports, a 120V AC coil, and a mounting bracket identified by option code 21; the three-port valve can be piped for normally closed, normally open, diverter, selector, or two-way service.

Part Details:

  • Humphrey 310 Series direct-acting solenoid valve with a pressure-balanced, spring-return poppet design
  • Three-port, two-position inline configuration for normally closed, normally open, diverter, or selector operation
  • Can be configured for two-way service by plugging the appropriate port
  • 120V AC, 50/60 Hz coil with 4.5-watt power consumption
  • 1/8-inch pipe ports for air and inert-gas service
  • Option code 21 mounting-bracket configuration

Documentation:

FAQs:

Q: What is the Humphrey 310-21 120V solenoid valve used for?
A: The Humphrey 310-21 120V is used to electrically direct or shut off airflow in pneumatic equipment and control circuits. Its three-port design supports normally closed, normally open, diverter, and selector arrangements, and it can also be used as a two-way valve when the appropriate port is plugged.

Q: Is the Humphrey 310-21 a normally closed or normally open valve?
A: The Humphrey 310-21 can be piped for either normally closed or normally open operation. The resulting function depends on how the pressure, outlet, and exhaust ports are connected, so check the equipment’s pneumatic diagram before selecting a replacement.

Q: What do “310,” “21,” and “120V” identify in the Humphrey 310-21 120V part number?
A: “310” identifies the three-way inline valve series, “21” is the option code for the mounting bracket, and “120V” identifies the coil voltage. Confirm the complete valve marking because other 310 Series configurations may use different voltages, electrical connections, mounting arrangements, or optional features.

Q: What specifications should be checked before replacing a Humphrey 310-21 120V valve?
A: Confirm the complete model marking, 120V AC coil requirement, 1/8-inch port size, required two-way or three-way function, normal operating state, pressure range, media, mounting arrangement, and electrical connection. A similar-looking 310 Series valve should not be considered interchangeable unless its complete configuration matches the application.

Q: Can the Humphrey 310-21 120V be used with vacuum or liquids?
A: The manufacturer identifies air and inert gases as the standard media for the 310 Series, while vacuum capability is associated with designated multipurpose or V310 applications. Liquid service is not verified for this exact configuration, so vacuum or nonstandard-media applications should be checked against the complete valve marking and current Humphrey specifications.
