Product Overview
KMC Controls Thermostat (CTE-5202)
The KMC Controls CTE-5202 is an electronic room thermostat designed to monitor space temperature and provide separate heating and cooling control signals within commercial HVAC systems. The thermostat features dual adjustable setpoints, an LCD interface, and two configurable 0-12 VDC outputs for integration with VAV equipment, proportional actuators, valves, and other control devices. It is commonly specified for single-duct and dual-duct VAV applications, fan-powered terminals, baseboard heating systems, and chilled beam installations.
Part Details:
- KMC Controls CTE-5202 dual-setpoint electronic room thermostat with LCD display
- Two independent PI (Proportional + Integral) control loops for separate heating and cooling control
- Dual configurable analog outputs with adjustable 0 to 12 VDC output span
- Operates on 24 VAC Class 2 power or 14 to 35 VDC supply voltage
- Supports multiple application sequences including single-duct VAV, fan-powered VAV, dual-duct VAV, baseboard heating, and chilled beam systems
- Functional replacement for many KMC CTE-100x, CTE-110x, CTE-50xx, CTE-51xx, and select Barber Colman TP-81xx thermostats
